incinerator manufacturer 200kgs/h
incinerator manufacturer 200kgs/h
Waste is thermally decomposed in the primary chamber at temperatures of 800 °C +. The resulting gaseous products are completely oxidized in the secondary chamber at higher temperatures with sufficient resident time. Other specifications are as follows. A combustion chamber of waste:
* Perfectly tight door for the manual loading of waste. The loading should be Manual, Batch Load
HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification)
* A burner of lighting which the use is limited to the ignition of waste.
* Frontage of loading with door seals gone up on hinges, wheel of screw plug, flexible joint, and stuffing insulating out of refractory.
* The insulation of the combustion chamber should be composed of refractory bricks, having a high content of aluminum and insulates bricks in order to assure a minimum temperature on the outside sheet metal.
* Composition of the refractory
HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification)
|
Burning Capacity |
Max. 200kgs/h |
|
|
Auxiliary Fuel |
Diesel |
|
|
Type of Burner |
Monoblock automatic burners |
|
|
Temperatures Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-13813931455(WhatsApp)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Add: Gangjia Zhihui Industrial Area, Xin Gangwan Rd. Liuhe, Nanjing, China 211500
HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification) |
Primary Chamber: 800°C ± 50°C Secondary Chamber: 1300°C ± 50°C |
|
|
Type |
Static solid hearth |
|
|
Material of Construction |
Mild Steel |
|
|
Refractory thickness |
115 mm thick Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-13813931455(WhatsApp)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Add: Gangjia Zhihui Industrial Area, Xin Gangwan Rd. Liuhe, Nanjing, China 211500
HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification) |
|
|
Material |
Refractory bricks |
|
|
Insulation thickness |
50 mm thick |
|
|
Waste Charging |
Manual |
|
|
Ash Removal Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-13813931455(WhatsApp)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Add: Gangjia Zhihui Industrial Area, Xin Gangwan Rd. Liuhe, Nanjing, China 211500
HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification) |
Manual |
|
|
Type |
Static solid hearth |
|
|
Material of Construction |
Mild Steel |
|
|
Refractory thickness |
115 mm thick |
|
|
Material |
Refractory bricks |
|
|
Insulation thickness Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-13813931455(WhatsApp)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Add: Gangjia Zhihui Industrial Area, Xin Gangwan Rd. Liuhe, Nanjing, China 211500
HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification) |
50 mm thick |
|
|
Type |
Centrifugal |
|
|
Modulation |
Manual damper control |
|
|
Material of Construction |
Mild Steel |
|
|
Type of temperature controller |
Digital |
|
|
Finish & painting type Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-13813931455(WhatsApp)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Add: Gangjia Zhihui Industrial Area, Xin Gangwan Rd. Liuhe, Nanjing, China 211500
HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification) |
Double coat |
|
|
Material of construction & capacity |
Mild Steel/ Plastic, suitable capacity |
|
|
Other Standard Accessories |
Diesel oil level indicator, piping with valves & Non-return valve |
|
|
Visual Checking of Fuel |
Provided |
|
|
No. of Burners |
2 one in primary and in secondary chamber) |
|
|
Type & Model |
Monoblock automatic oil fired |
|
|
Make |
Riello |
|
|
Fuel |
Diesel |
|
|
Fuel delivery |
10 �C 20 kg/h |
|
|
Firing stage |
1 |
|
|
Thermal power |
118 �C 236 kW |
|
|
Motor power |
240 W |
|
|
Pump pressure |
10 �C 12 bar (standard calibration), Max. pressure 15 bar |
|
|
Electrical supply |
Single phase 220V, 50Hz. |
|
|
Material of construction |
Burnt bricks |
|
|
Height |
9 meters from ground level |
|
